CO-DRIP Composite & PET Strapping Production Line India

Name: Composite & Polyester Fiber Strapping Production Line
Brand: CO-DRIP
Availability: InStock

About the Principal

About CO-DRIP

CO-DRIP factory and manufacturing facility

CO-DRIP, Qingdao CO-DRIP Irrigation Machinery Co., Ltd., manufactures the composite and polyester strapping production line that Magnum Resources supplies in India. The line converts polyester yarn and PE resin into high-strength industrial strap, with two practical configurations: composite cord strap from 9 to 32mm and wider Geo strap from 40 to 100mm for heavier bundling applications.

The system runs with PLC control, automatic break detection and on-line water-tank temperature sensing, built around ISO and EU quality standards. Magnum Resources handles pre-sales sizing, customs clearance, installation, start-up, operator training, AMC and genuine spare parts directly through CO-DRIP's Qingdao factory, so buyers have one accountable India contact after commissioning.

Machine Range

CO-DRIP Composite & PET Strapping Production Line

A single-machine focus. Two configurations from one CO-DRIP production line family: composite cord strap for general industrial packaging, and wider Geo strap for heavy cargo bundling. Both supplied, installed and serviced by Magnum Resources across India.

Composite & Polyester Fiber Strapping Production Line - CO-DRIP machine supplied by Magnum Resources India

Flagship Machine

Industrial Strapping Production Lines

Composite & Polyester Fiber Strapping Production Line

Make high-strength composite cord strap and polyester fiber strap in-house, as a rust-free, safer alternative to steel banding.

Two configurations from one machine family — composite cord strap (9-32mm) or wide-format Geo strap (40-100mm)
PLC-controlled operation with on-line water-tank sensing and automatic break detection
Polyester yarn + PE coating process, diamond-knurled for buckle grip — ISO + EU quality standards
Authorised India distributor — pre-sales sizing, customs, installation, training and AMC by Magnum Resources

View Full Machine Details → Request datasheet & quote →

Two Configurations at a Glance

One CO-DRIP production line, two factory configurations. Choose the one that matches the strap width, tonnage and end-market your buyers demand.

Configuration A

Composite Cord Strap Line

General industrial packaging — paper mills, lumber yards, brick manufacturers, steel coil binding.

Strap width: 9 to 32 mm
Line speed: 120 m/min
Output capacity: 100 to 200 kg/h
Installed power: 60 to 110 kW
Output per pass: 1 or 2 strips

Configuration B

Geo Strap Line — Wide Format

Heavy cargo bundling — steel coils, paper-mill reels, oversized timber, block and tile packaging.

Strap width: 40 to 100 mm
Line speed: 20 to 60 m/min
Output capacity: 300 to 450 kg/h
Installed power: 90 to 120 kW
Output per pass: Single strip

Industries Served

Where CO-DRIP Machines Are Used

The CO-DRIP composite and PET strapping production line serves these manufacturing segments in India. Magnum Resources provides pre-sales sizing, installation, operator training and AMC for buyers in each segment.after-sales service

Existing PET Strap Manufacturers

For PET and polyester strap makers in Gujarat, Maharashtra, Delhi NCR, Tamil Nadu and beyond looking to add a second line, expand monthly tonnage, or upgrade older extrusion equipment with a PLC-controlled CO-DRIP production system.

Composite Cord Strap Producers

For manufacturers entering or expanding in the composite cord strap segment, marketed as an alternative to steel strapping. Polyester yarn plus extruded PE coating, with single or twin-strip output configurations for higher throughput per shift.

Geo Strap & Wide-Format Strap

For producers targeting heavy bundling applications where wider 40 to 100mm Geo strap is required: steel coil binding, lumber and timber bundling, brick and block packaging, paper-mill reel binding and other heavy-load cargo.

New Strap Manufacturing Entrants

For entrepreneurs and packaging companies setting up captive or commercial strap production. A turnkey extrusion-to-winding line supplied, installed and brought online by Magnum Resources, with operator training and AMC included.

Solutions Powered by CO-DRIP

Industry Solutions Where CO-DRIP Plays a Role

CO-DRIP machines are the backbone of these Magnum Resources industry solutions. Click through to see the full solution stack.

The CO-DRIP Advantage

Why CO-DRIP

What sets the CO-DRIP composite and PET strapping production line apart, and why it deserves a serious look from Indian strap manufacturers planning a new line or capacity expansion.

01

Two Configurations, One Machine Family

Composite cord strap (9 to 32mm, 120 m/min, 100 to 200 kg/h) and Geo strap (40 to 100mm, 20 to 60 m/min, 300 to 450 kg/h). One supplier, one accountability chain, tuned to the strap width and tonnage your market demands.

02

PLC Control + Online Monitoring

Full PLC-controlled operation with automatic water-tank temperature sensing and on-line process monitoring. Automated break detection with alarm function reduces unplanned downtime and protects yarn inventory from runaway feed.

03

Single or Twin-Strip Output

The composite cord strap configuration produces 1 or 2 strips per pass. Higher throughput per shift without doubling floor space, electrical load or operator headcount, a direct improvement to your per-metre cost.

04

Polyester Yarn + PE Coating Process

Polyester yarn is fed from creels, sheathed in extruded PE, diamond-knurled via indented rollers and cooled in a controlled-temperature trough. Tensile strength is preserved across the full process; the diamond pattern improves buckle grip and tension retention.

05

ISO + EU Quality Standards

Manufactured to ISO and EU quality standards, with installed power 60 to 110 kW (composite) or 90 to 120 kW (Geo). Already running in European export markets and exhibited at CHINAPLAS 2026.

06

Authorised India Distributor

Magnum Resources is the authorised distributor of this CO-DRIP machine in India. A single point of accountability for pre-sales engineering, customs clearance, start-up, operator training, AMC and genuine spare parts.

Why Magnum Resources

Why Magnum Resources for CO-DRIP

A principal is only as good as the partner supporting them in your country. Here's what we bring to your CO-DRIP purchase.

Authorized India distributor

Pan-India Sales & service coverage

Direct Factory pricing & support

Factory Genuine spare parts supply

Magnum Resources is the authorised India distributor for the CO-DRIP composite and PET strapping production line. We provide pre-sales sizing, customs clearance, on-site installation, operator training and AMC contracts, with genuine spare parts supplied directly from CO-DRIP's Qingdao factory to your production floor anywhere in India.

Frequently Asked Questions

Buying CO-DRIP in India — Quick Answers

What does the CO-DRIP strapping machine actually produce?

Two strap types from one machine family. Composite cord strap in 9 to 32mm widths, and wider Geo strap in 40 to 100mm widths. Both are polyester-yarn-core straps with an extruded PE coating, used as a cost-effective alternative to steel strapping in industrial packaging.

What is the output capacity of the CO-DRIP strapping line?

The composite cord strap configuration runs at 120 m/min line speed with 100 to 200 kg/h output and 1 or 2 strips per pass. The wider Geo strap configuration runs at 20 to 60 m/min with 300 to 450 kg/h output. Total installed power is 60 to 110 kW for composite and 90 to 120 kW for Geo strap.

Is the CO-DRIP strapping production line available in India?

Yes. Magnum Resources is the authorised India distributor for this CO-DRIP machine. Sales, installation, start-up, operator training, AMC and genuine spare parts are available, with technical and parts support coordinated directly with CO-DRIP's Qingdao factory.

How does composite strap compare to steel strapping?

Composite cord strap is as strong as steel for most binding applications, weather-resistant, lighter per metre, safer to handle (no sharp edges or sprung-back injuries), shock-absorbing under tension and printable for brand marking. The material cost per metre is typically lower than steel for equivalent break strength, which is why paper mills, lumber yards and brick manufacturers are switching.

What raw materials does this machine process?

Polyester yarn fed from creels, plus PE (polyethylene) resin for the extruded coating layer. The polyester yarn supplies the tensile strength; the PE sheath provides UV resistance, abrasion resistance and a printable surface. Both raw materials are widely available from Indian polymer and yarn suppliers.

Who typically buys this CO-DRIP production line?

Existing PET and polyester strap manufacturers expanding capacity or upgrading older equipment, manufacturers entering the composite cord strap segment, and packaging companies setting up captive or commercial strap production. The two configurations cover both general packaging strap and wide-format heavy-cargo bundling markets.

What is the typical delivery time for a CO-DRIP machine to India?

Standard production lines typically ship within 12 to 16 weeks from the Qingdao factory, depending on configuration and current factory load. Loading is from Qingdao or Shanghai seaport. Contact our team for current lead times and full landed-cost estimates including customs duties.

Does Magnum Resources provide installation and AMC for CO-DRIP machines?

Yes. On-site installation, start-up, operator training, preventive maintenance contracts (AMC) and service support across India. Genuine CO-DRIP spare parts are supplied directly from the Qingdao factory.
